INSTALL & CONFIGURE ELK STACK 7.3 ON CENTOS7

INTRODUCTION

Hi Folks, In this tutorial I’m going to install & configure ELK Stack as a Log server inside my testing Lab.

“ELK” is the acronym for the three open source projects call Elasticsearch, Logstash and Kibana. ELK stack made easier to analyze logs to system administrators. ELK stack collect logs from clients using Beats protocol

ELK STACK MAIN COMPONENTS

Elasticsearch is an open source, distributed, RESTful, JSON based search and analytic engine. Easy to use and flexible. Elasticsearch is the heart of ELK stack. Elasticsearch is a No-SQL database.

Logstash is a open source, server-side data processing pipeline that pull events data from multitude of sources simultaneously, transform it, and then sends it to Elasticsearch. Easily pull data from logs, metrics, web applications, data sources and various AWS services. Logstash dynamically transforms and prepares data regardless of format or complexity. Derive structure from unstructured data with grock.

Kibana provides GUI for users visualize data with charts and graphs real-time. It is a window into the Elastic Stack. Provides data exploration, visualization and dashboarding.

Beats is the platform for single-purpose data shippers. They install as lightweight agents and send data from numerous machines to Logstash of

Software Versions I have used in this tutorial.

Host	IP	Server/Client
elk.da.com	192.168.10.10	Server
cl1.da.com	192.168.10.110	Client

Package	Version
Elasticsearch	Version: 7.3
Logstash	Version: 7.3
Kibana	Version: 7.3
Java JDK	jdk-11.0.4

STEP 1: COMPLETE PREREQUSITES

A: SET HOSTNAME & FQDN

vim /etc/hostname

elk

vim /etc/hosts

192.168.10.10   elk.da.com  elk

B: CLEAR AND REMOVE YUM CACHE (OPTIONAL)

sudo rm /etc/yum.repos.d/$REPONAME.repo
yum clean all

Delete the yum cache for the repo

sudo rm -rf /var/cache/yum/x86_64/6/$REPONAME

Clearing the yum Caches

su -c 'yum clean headers'
su -c 'yum clean packages'
su -c 'yum clean metadata'

C: INSTALL AND UPDATE LATEST RPM REPOSITORIES

rpm -ivh https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm

rpm -ivh https://mirror.webtatic.com/yum/el7/webtatic-release.rpm

rpm -ivh http://rpms.famillecollet.com/enterprise/remi-release-7.rpm

rpm -ivh https://download1.rpmfusion.org/free/el/rpmfusion-free-release-7.noarch.rpm

rpm -ivh http://repository.it4i.cz/mirrors/repoforge/redhat/el7/en/x86_64/rpmforge/RPMS/rpmforge-release-0.5.3-1.el7.rf.x86_64.rpm

D: SELINUX CONFIGURATION

vim /etc/selinux/config

SELINUX=permissive

STEP 3: INSTALL JAVA JDK

Java is required for the Elastic stack deployment. Elasticsearch requires Java 8, it is recommended to use the Oracle JDK 1.8. I will install Java 8 from the official Oracle rpm package. ELK requires the Oracle Java JDK package has to be installed. The same JVM version should be installed on all Elasticsearch nodes and clients.

A: DOWNLOAD JAVA JDK 11.0.4

curl -o jdk-11.0.4_linux-x64_bin.rpm https://download.oracle.com/otn/java/jdk/11.0.4+10/cf1bbcbf431a474eb9fc550051f4ee78/jdk-11.0.4_linux-x64_bin.rpm?AuthParam=1566470470_04821224cc5f90794bc98fdb1d1b171a

B: INSTALL JDK RPM 11.0.4

rpm -ivh jdk-11.0.4_linux-x64_bin.rpm

C: SET DEFAULT JAVA VERSION

alternatives --config java

alternatives --set jar /usr/java/jdk-11.0.4/bin/jar

alternatives --set javac /usr/java/jdk-11.0.4/bin/javac

D: SET JAVA ENVIRONMENT VARIABLES

SET JAVAC AND JAR PATHS

export JAVA_HOME=/usr/java/jdk-11.0.4/
export PATH=$PATH:/usr/java/jdk-11.0.4/bin/

vim ~/.bashrc

export JAVA_HOME=/usr/java/jdk-11.0.4/
export PATH=$PATH:/usr/java/jdk-11.0.4/bin/

vim ~/.bash_profile

export JAVA_HOME=/usr/java/jdk-11.0.4/
export PATH=$PATH:/usr/java/jdk-11.0.4/bin/

E: CHECK JAVA VERSION

java -version

java version "11.0.4" 2019-07-16 LTS
Java(TM) SE Runtime Environment 18.9 (build 11.0.4+10-LTS)
Java HotSpot(TM) 64-Bit Server VM 18.9 (build 11.0.4+10-LTS, mixed mode)

STEP 3: INSTALL AND CONFIGURE ELASTICSEARCH

In this step, I will install and configure Elasticsearch version 7.3

A: IMPORT PUBLIC GPG KEY TO THE ELK-STACK SERVER

rpm --import https://artifacts.elastic.co/GPG-KEY-elasticsearch

B: CREATE YUM REPO FILE FOR ELASTICSEARCH

vim /etc/yum.repos.d/elasticsearch.repo

[elasticsearch-7.x]
name=Elasticsearch repository for 7.x packages
baseurl=https://artifacts.elastic.co/packages/7.x/yum
gpgcheck=1
gpgkey=https://artifacts.elastic.co/GPG-KEY-elasticsearch
enabled=1
autorefresh=1
type=rpm-md

C: INSTALL ELASTICSEARCH YUM PACKAGES

sudo yum -y install elasticsearch

CONFIGURE ELASTICSEARCH

Do the following changes

vim /etc/elasticsearch/elasticsearch.yml

cluster.name: elk
node.name: node-1
path.data: /var/lib/elasticsearch
path.logs: /var/log/elasticsearch
network.host: 127.0.0.1
http.host: 0.0.0.0
http.port: 9200

JVM Options Configuration

Set initial/maximum size of total heap space. If your system has less memory. You should configure it to use small megabytes of ram.

vim /etc/elasticsearch/jvm.options

-Xms4g
-Xmx4g

FIREWALL CONFIGURATION

Allow traffic through the TCP port 9200 in the firewall.

firewall-cmd --permanent --add-port=9200/tcp

firewall-cmd --permanent --add-port=9300/tcp

firewall-cmd --reload

START & ENABLE ELASTICSEARCH AT SYSTEM BOOT

sudo yum install elasticsearch

sudo /bin/systemctl daemon-reload

sudo /bin/systemctl enable elasticsearch.service

sudo /bin/systemctl restart elasticsearch.service

sudo /bin/systemctl status -l elasticsearch.service

sudo journalctl -f

sudo journalctl --unit elasticsearch

TEST ELASTICSEARCH

Check Elasticsearch port “9200” state as “LISTEN”

netstat -plntu

OPEN IN BROWSER

http://192.168.10.10:9200/?pretty

OPEN IN TERMINAL

curl -XGET '192.168.10.10:9200/?pretty'

STEP 4: INSTALL AND CONFIGURE LOGSTASH

In this step I will install Logstash version 7.3 and configure it as a central log server, receives logs from clients with Filebeat/Auditbeat, then filter and transform the syslog/Audit data and move it into the stash (Elasticsearch)

A: IMPORT PUBLIC GPG KEY TO THE ELK-STACK SERVER

rpm --import https://artifacts.elastic.co/GPG-KEY-elasticsearch

B: CREATE YUM REPO FILE FOR ELASTICSEARCH

vim /etc/yum.repos.d/logstash.repo

[logstash-7.x]
name=Elastic repository for 7.x packages
baseurl=https://artifacts.elastic.co/packages/7.x/yum
gpgcheck=1
gpgkey=https://artifacts.elastic.co/GPG-KEY-elasticsearch
enabled=1
autorefresh=1
type=rpm-md

C: INSTALL LOGSTASH YUM PACKAGES

sudo yum -y install logstash

NOTE: Need to genarate SSL Certificate if you using SSL.This step is optional

GENERATE A NEW SSL CERTIFICATE Create new ssl certificate for securing communication between Logstash & Filebeat (clients). SSL Certificate file use clients to identify the elastic server.

Do the following changes under the “[ V3_ca ]” section for the server identification.

vim /etc/pki/tls/openssl.cnf

[ v3_ca ]
#Server IP Address
subjectAltName = IP: 192.168.10.10

Generate the certificate file with the openssl command.

openssl req -config /etc/pki/tls/openssl.cnf -x509 -days 3650 -batch -nodes -newkey rsa:2048 -keyout /etc/pki/tls/private/logstash-forwarder.key -out /etc/pki/tls/certs/logstash-forwarder.crt

Once ssl certificate is ready, this certificate should be copied to all the clients using scp command.

D: CONFIGURE LOGSTASH

vim /etc/logstash/logstash.yml

path.data: /var/lib/logstash
http.host: "192.168.10.10"
path.logs: /var/log/logstash

sudo /bin/systemctl daemon-reload

sudo /bin/systemctl enable logstash.service

sudo /bin/systemctl restart logstash.service

sudo /bin/systemctl status -l logstash.service

sudo journalctl -f

sudo journalctl --unit elasticsearch

E: JVM CONFIGURATION

vim /etc/logstash/jvm.options

-Xms4g
-Xmx4g

F: CREATE FOLLOWING FILES UNDER /ETC/LOGSTASH/CONF.D/ DIRECTORY.

vim /etc/logstash/conf.d/auditbeat.conf

### INPUT SECTION ###
### This section make Logstash to listen on port 5044 for incoming logs & provides SSL certificate for secure connection.
input {
  beats {
    port => 5044
#   ssl => true
#   ssl_certificate => "/etc/pki/tls/certs/logstash-forwarder.crt"
#   ssl_key => "/etc/pki/tls/private/logstash-forwarder.key"
  }
}

### OUTPUT SECTION ###
### This section defines the storage for the logs to be stored.
output {
  elasticsearch {
    hosts => ["http://192.168.10.10:9200"]
    manage_template => false
    index => "%{[@metadata][beat]}-%{[@metadata][version]}-%{+YYYY.MM.DD}"
    document_type => "%{[@metadata][type]}"
  }
}

G: FIREWALL CONFIGURATION

Allow traffic through the TCP port 5044 in the firewall.

firewall-cmd --permanent --add-port=5044/tcp
firewall-cmd --reload

ENABLE & START LOGSTASH SERVICE

sudo /bin/systemctl daemon-reload
sudo /bin/systemctl enable logstash.service
sudo /bin/systemctl restart logstash.service
sudo /bin/systemctl status -l logstash.service
sudo journalctl -f
sudo journalctl --unit elasticsearch

STEP 5: INSTALL AND CONFIGURE KIBANA

A: IMPORT PUBLIC GPG KEY TO THE ELK-STACK SERVER

rpm --import https://artifacts.elastic.co/GPG-KEY-elasticsearch

B: CREATE YUM REPO FILE FOR KIBANA

vim /etc/yum.repos.d/kibana.repo

[kibana-7.x]
name=Kibana repository for 7.x packages
baseurl=https://artifacts.elastic.co/packages/7.x/yum
gpgcheck=1
gpgkey=https://artifacts.elastic.co/GPG-KEY-elasticsearch
enabled=1
autorefresh=1
type=rpm-md

C: INSTALL KIBANA YUM PACKAGES

sudo yum install kibana

D: CONFIGURE KIBANA

vim /etc/kibana/kibana.yml

server.port: 5601
server.host: "0.0.0.0"
server.name: "elk"
elasticsearch.hosts: ["http://127.0.0.1:9200"]

E: FIREWALL CONFIGURATION

Allow traffic through the TCP port 5044 in the firewall.

firewall-cmd --permanent --add-port=5601/tcp
firewall-cmd --reload

F: ENABLE & START LOGSTASH SERVICE

sudo /bin/systemctl daemon-reload

sudo /bin/systemctl enable kibana.service

sudo /bin/systemctl restart kibana.service

sudo /bin/systemctl status -l  kibana.service

netstat -tulpena | grep 5601

STEP 6: INSTALL AND CONFIGURE NGINX

A: INSATLL EPEL REPOSITORY

yum install epel-release

B: INSTALL NGINX & HTTPD-TOOLS

yum install nginx httpd-tools

CREATE USERNAME “ADMIN” AND PASSWORD “PASSWORD” FOR KIBANA WEB INTERFACE

htpasswd -c /etc/nginx/htpasswd.kibana admin

C: CONFIGURE NGINX

Edit the Nginx configuration file and remove the ‘server { }’ block, so we can add a new virtual host configuration.

vim /etc/nginx/nginx.conf

COMMENT {Server} Block:

Create new virtual host configuration file named “kibana.conf” under the conf.d directory.

D: CREATE VHOST FOR KIBANA:

vim /etc/nginx/conf.d/kibana.conf

server {
    listen 80;

    server_name elk-stack.co;

    auth_basic "Restricted Access";
    auth_basic_user_file /etc/nginx/htpasswd.kibana;

    location / {
        proxy_pass http://localhost:5601;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_cache_bypass $http_upgrade;
    }
   }

E: CHECK NGINX CONFIGURATION

nginx -t

F: FIREWALL CONFIGURATION

Allow traffic through the TCP port 80 in the firewall.

firewall-cmd --permanent --add-port=80/tcp
firewall-cmd --permanent --add-service=http
firewall-cmd --reload

G: ENABLE & START NGINX SERVICE

systemctl enable nginx.service
systemctl restart nginx.service

SELINUX CONFGURATION

setsebool -P httpd_can_network_connect 1

STEP 07: CONNECT KIBANA FRONTEND WITH ELASTICSEARCH

YOU NEED ASSIGN KIBANA TO WHICH ELASTICSEARCH INDECES YOU WANT YO EXPLORE.

Configure the Elasticsearch Indices what you want to access with Kibana.

Open Web Browser and Point To… (Only via Kibana) http://YOURIP.com:5601

OR

(If nginx/apache proxy redirect with VHOST) http://YOURIP.com:80
